FTP CAT5E CABLE CONSTRUCTILN:
|
|
Part No.
|
Designation
|
AWG size
|
Conductor
|
Insulation
|
Sheath
|
Weight
|
|
382001
|
FTP CAT.5e
|
4X2X24AWG
|
0.51mm
|
0.92mm
|
5.3mm
|
33.8kg
|
|
|
ELECTRICAL CHARACTERISTICS:
|
|
Frequency
MHz
|
Attenuation Max
|
Crosstalk NEXT
|
Crosstalk
|
Power Sum
|
Impedance
|
Return Loss
|
|
db/100m
|
db/100m
|
db/100m
|
db/100m
|
Ohm
|
db/100m
|
|
Max.
|
Nom.
|
Min.
|
Nom.
|
Min.
|
Nom.
|
Min.
|
Nom.
|
Ω
|
Min.
|
Nom.
|
|
1
|
1.6
|
1.9
|
106.9
|
74
|
94.7
|
68
|
84.0
|
65
|
100±10
|
29.3
|
20.0
|
|
4
|
3.2
|
3.7
|
96.1
|
65
|
81.1
|
526
|
74.1
|
53
|
100±10
|
35.1
|
23.0
|
|
10
|
5.2
|
5.9
|
89.1
|
59
|
75.0
|
48
|
61.7
|
45
|
100±10
|
42.2
|
25.0
|
|
16
|
6.6
|
7.5
|
85.5
|
56
|
73.8
|
44
|
56.9
|
41
|
100±10
|
44.1
|
25.0
|
|
20
|
7.5
|
8.4
|
83.1
|
55
|
67.0
|
42
|
55.0
|
339
|
100±10
|
38.5
|
25.0
|
|
31.25
|
9.6
|
10.6
|
81.2
|
52
|
64.3
|
38
|
51.7
|
35
|
100±10
|
39.6
|
23.6
|
|
62.50
|
13.8
|
15.4
|
75.2
|
47
|
59.4
|
32
|
50.5
|
29
|
100±10
|
38.2
|
21.5
|
|
100
|
17.8
|
19.8
|
71.5
|
44
|
49.1
|
28
|
39.5
|
25
|
100±10
|
35.3
|
20.1
|
|
200
|
26.2
|
29.0
|
67.4
|
40
|
44.7
|
22
|
37.6
|
19
|
100±15
|
30.1
|
18.0
|
|
250
|
30.0
|
32.8
|
58.6
|
38
|
38.0
|
20
|
35.2
|
17
|
100±15
|
25.8
|
17.3
|
|
